5mm LED Indicators / Ø6.1mm Panel Cut Out / 7.6mm Bezel

DX 0998 / 1120 / 1121 / 1090 / 1092 / 1091 / 1093 Series

    • 5mm LED Indicators
    • Choice of profile, depending on part code prefix:
    • DX0998, DX1120, DX1090, DX1091: Recessed profile
    • DX1121, DX1092, DX1093: Prominent profile
    • Choice of Bezel material, depending on part code prefix:
    • DX0998: Chrome Plated Brass
    • DX1120, DX1121: Glass Filled Nylon
    • DX1091, DX1093: Anodised Aluminium
    • DX1090, DX1092: Black Anodised Aluminium
    • All Aluminium bodied parts are IP66 Front Panel Sealed
    • Choice of Illumination colour depending on part code:
    • Single colour LED: /RD - Red, /GN - Green, /YL - Yellow, /BL - Blue
    • Dual colour LED: /D1 - Red/Green, /D2 - Red/Amber, /D3 - Green/Amber
    • Tri-colour LED: /TR - Red/Green/Amber
    • Flashing LED: /RD/02 - Red, /GN/02 - Green
    • No resistor installed; see data for ratings to enable calculation of suitable series resistor value for application
